The NiTO CLICK couplings and adapters are interchangeable with the most common plastic quick couplings and adapters and simplify the connection of spray guns to hoses, lances and any other components. These water couplings are available in brass-chromed and are divided into a 1/2″, 3/4″ series.
AK6950SA3, NiTO 3/4″ CLICK coupler
Description
Additional information
| Version |
3/4" series |
|---|---|
| Connection |
19mm hose tail |
| Material body |
Chrome plated brass (CuZn39Pb3) |
| Material of the spring & locking ring |
Stainless steel (AISI 301) |
| Material of the balls |
Stainless steel (AISI 420) |
| Material of the seals |
NBR |
| Maximum pressure (bar) |
25 |
| Temperature range (°C) |
-30 / +80 |
| Weight (kg) |
0, 092 |
| HS-code |
74032100 |
